JYM-15-50-5-AZZAH-PS2.0
金钰铭
Availability: | |
---|---|
Function parameter table
Calibration medium: pure tap water;
Number of inspection meters: 5 DN15, 5 DN20, 5 DN25, 1 DN32, 1 DN40, 1 DN50;
Working voltage: AC220V
Flow range: (0.006~40) m³/h;
Water source working pressure: 0.2-1.0Mpa
Adjustable, air source working pressure: 0.4-0.7MPa;
Meter clamping mechanism: single meter independent pneumatic meter clamping device;
Water pump: Nanfang water pump CHM3-10, flow rate 50m³/h, head 30 meters
Water tank: 200L
Meets DN15-DN50 4000 accelerated durability test requirements
Meets DN15-DN50 2400 hours basic durability test requirements
Meets DN15-DN50 500 hours additional durability test requirements
